Rahmen: Alloy 6061, All Mountain, 140mm, Integrated Battery, 12x148mm
Gabel: Rock Shox Recon Silver RL, Motion Control, 150mm, Tapered
Dämpfer:Rock Shox Deluxe Select+ RL, 230x57mm
Antrieb:Yamaha PW-ST, 250W, 70Nm
Display:Yamaha Display A, LCD-Display
Bedieneinheit: integrated in display
Akku:Yamaha ML500, 36V, 14Ah
Ladegerät:Yamaha, Fast Charger, 4A
Lenker: R Raymon 31.8, 760mm, Sweep: 9°, Rise: 15mm
Griffe: R Raymon MTB, Lock-On
Vorbau: R Raymon 31.8, 45mm, 0°
Bremsen vorne: Shimano BR-MT420, hydr. Disc, 4-piston
Bremsen hinten: Shimano BR-MT410, hydr. Disc
Rücktrittbremsen Option: no
Sattel: R Raymon MTB
Sattelstütze:R Raymon 31.6, Dropper Post, S: 420mm; M/L/XL: 447mm
Schaltwerk:Shimano Deore, RD-M5100, Shadow Plus, 11-speed
Schalthebel links:Shimano Deore, SL-MT500, Seat Post Lever
Schalthebel rechts:Shimano Deore, SL-M5100, Rapidfire Plus, 11-speed
Kassette:Shimano CS-M5100, 11-51T, 11-speed
Kette: KMC e11S
Kurbelgarnitur: R Raymon, Alloy, 165mm
Kettenblatt:R Raymon, Narrow Wide, 38T
Laufradsatz:Rim: Mach1 Trucky, Hubs: R Raymon DA210, 15x110/12x148mm
Reifen vorne: Schwalbe Nobby Nic, Performance, Tubeless, 65-584, 27.5x2.60
Reifen hinten: Schwalbe Nobby Nic, Performance, Tubeless, 65-584, 27.5x2.60
Pedale: R Raymon, Alloy
Anhänger kompatibel: yes
Farbe: Spaceblue / Magma Matt
Modellfamilie: FullRay E-Seven
Rahmenform: E-MTB-All-Mountain
